Corning® HTS Transwell®-96 Permeable Support with 0.4 microns Pore Polycarbonate/PET Membrane, Sterile

  • EVM-AC-03-C3381
  • EVM-AC-03-C3384
$386
$386

EVM-AC-03-C3381

From $386 - $1,928
From $386 - $1,928
Case of

Prices valid in USA, Canada, and PR only.

  • Product includes: Transwell® unit (1 integral tray with 96 wells), reservoir plate (for cell growth steps), receiver plate (96 wells for growth or assay steps) and 2 sterile lids
  • 0.4 µm pore size PC (polycarbonate) membrane (EVM-AC-03-C3381, EVM-AC-03-C3391)
  • 0.4 µm pore size PET membrane (EVM-AC-03-C7369)
  • Membrane is treated for optimal cell attachment
  • Receiver and reservoir plates are untreated
  • Cell growth area is 0.143 cm² which is 20-50% greater than other brands
  • Large apical and basolateral access ports
  • Automation optimized design with multi-channel feeder ports, improved gripping surface and bar coding

One or more facilities manufacturing this product is 100% covered by renewable energy through the purchase of unbundled energy attribute certificates (EACs).

Details

Options

Order code Corning P/N Description Case of
EVM-AC-03-C3381 3381 Corning® HTS Transwell®-96 Permeable Support with 0.4 µm Pore Polycarbonate Membrane, 1 per Case, Sterile 1
EVM-AC-03-C3391 3391 Corning® HTS Transwell®-96 Permeable Support with 0.4 µm Pore Polycarbonate Membrane, 5 per Case, Sterile 5
EVM-AC-03-C7369 7369 Corning® HTS Transwell®-96 Permeable Support with 0.4 µm PET Membrane, 5 per Case, Sterile 5

EVOM™Compatibility:

These HTS plates are compatible with WPI’s EVOM™ Manual (EVM-MT-03-02, EVM-MT-03-01, EVOM3), EVOM2 older meters when used with the compatible electrode.

Order code Compatible Electrode

EVM-AC-03-C3381

EVM-AC-03-C3391

EVM-AC-03-C7369

STX HTS EVOM™ Electrode for CORNING 96 (EVM-EL-03-03-05)



These HTS plates can be used with WPI’s EVOM™ Auto

Compatible System  Compatible Electrode  Additional Accessory/ Consumable Required for EVOM™ Auto

EVOM™ AUTO for TEER Measurement In 24/96 HTS Plate (EVA-MT-03-01)

Note: EVA-MT-03-01 includes EVA-EL-03-01

EVOM™ Auto 96 HTS Electrode Array (EVA-EL-03-01)







Not required







Resources

EVM-AC-03-C3381 Product Descriptions

EVM-AC-03-C3391 Product Descriptions

EVM-AC-03-C7369 Product Descriptions

Specifications

Type



EVM-AC-03-C3381

(Corning P/N 3381)

EVM-AC-03-C3391

(Corning P/N 3391)

EVM-AC-03-C7369

(Corning P/N 7369)
Qty./Pk 1 / Pk 5 / Pk 5 / Pk
Qty./Cs 1 / Cs 5 / Cs 5 / Cs
Brand Corning®  Corning®  Corning®
Plate Format 96-well 96-well 96-well
Cell Growth Area 0.143 cm² (approx.) 0.143 cm² (approx.) 0.143 cm² (approx.)
Recommended Medium Well Volume 0.235 mL   0.235 mL   0.235 mL
Recommended Medium Insert Volume 0.075 mL 0.075 mL 0.075 mL
Sterile  Yes  Yes Yes
Membrane Material Polycarbonate Polycarbonate Polyester (PET)
Membrane Pore Size 0.4 µm 0.4 µm 0.4 µm
Membrane Diameter 4.26 mm 4.26 mm 4.26 mm
Application     Air-Liquid Interface (ALI) Cultures
